Product Introduction:
✱ It is widely used in the infusion or approval of LED lighting products or other electronic appliances;
✱ The biggest feature of this product is its strong adhesion to acrylic or similar materials；
✱ It has good heat dissipation, which can ensure that the service life of the components will not be affected by excessive temperature during use；
✱ It has excellent weather resistance and can ensure that the lighting can be used normally in a wide temperature range (-60~200°C) environment, so that the use of the lighting is almost unlimited;
Basic parameters of the product (non-absolute value, for reference only):
| Indicators | Curing agent 3801 A | Resin agent 3801 B |
| Appearance | Black | Transparent |
| Viscosity (CPS) | 2000±500 | 50±5 |
| Mixed viscosity (CPS) | 1050±250 |
| Density(g/cm³ .25℃) | 1.22±0.05 | 0.95±0.05 |
| Usage ratio (weight ratio) | A:B=10:1 |
| Operable time 100g (min. 25 ℃) | 60±10 |
| Curing conditions | Room temperature curing or heating curing |
| Gel time (min.25 ℃) | 120 |
| Color (After curing) | Black
|
| Hardness (ShoreA/D) | 20±5A |
| Curing time （23~25℃） | 5-7H |
| Curing time (Heating) | / |
| Temperature resistance (℃) | -60℃~200℃ |
| Water absorption (24H) | ≤1% |
| Anti-UV Grade（GB/T14522-2008） | / |
| Volume resistivity (Ω.cm) | 1.0×1013 |
| Dielectric constant (1K Hz) | 3.8 |
| Tensile strength (MPa) | / |
| Ultimate elongation（%） | / |
| Average coefficient of linear expansion | 200×10-6K-1 |
The online data is for reference only, please contact us to get the latest version, and the official TDS data shall prevail.
