Product Introduction:
✱ It is widely used in the infusion or approval of LED lighting products or other electronic appliances;
✱ The glue has high light transmittance, forms an excellent transparent protective layer, and has strong UV resistance；
✱ It has good heat dissipation, which can ensure that the service life of the components will not be affected by excessive temperature during use；
✱ It has excellent weather resistance and can ensure that the lighting can be used normally in a wide temperature range (-60~200°C) environment, so that the use of the lighting is almost unlimited;
Basic parameters of the product (non-absolute value, for reference only):
| Indicators | Curing agent 3500 A | Resin agent 3500 B |
| Appearance | Transparent | Transparent |
| Viscosity (CPS) | 1000±200 | 850±200 |
| Mixed viscosity (CPS) | 1000±200 |
| Density(g/cm³ .25℃) | 0.96±0.05 | 0.95±0.05 |
| Usage ratio (weight ratio) | A:B=1:1 |
| Operable time 100g (min. 25 ℃) | 20±3 |
| Curing conditions | Room temperature |
| Gel time (min.25 ℃) | 45-60 |
| Color (After curing) | Transparent |
| Hardness (Shore 00) | 20±5 |
| Curing time （23~25℃） | 3-4H |
| Curing time (Heating) | 80 ℃ for 30minutes |
| Temperature resistance (℃) | -60℃~200℃ |
| Water absorption (24H) | ≤0.1% |
| Anti-UV Grade（GB/T14522-2008） | / |
| Volume resistivity (Ω.cm) | 1.0×1013 |
| Dielectric constant (1K Hz) | 3.8 |
| Tensile strength (MPa) | / |
| Ultimate elongation（%） | / |
| Average coefficient of linear expansion | 195×10-6K-1 |
The online data is for reference only, please contact us to get the latest version, and the official TDS data shall prevail.
