Product Introduction:
✱ Two-component polyurethane, convenient process operation, moderate fluidity, easy perfusion, good operability.
✱ The product meets the environmental protection requirements of RoHS/Reach and meets the flame retardant requirements of UL-V0 level.
✱ Excellent adhesion, good weather resistance, electrical propertiesElectrical properties.
✱ It is mainly used in the glue filling and waterproof protection of home appliance control boards, and is widely used in washing machine control boards, bathroom control boards, etc
Basic parameters of the product (non-absolute value, for reference only):
| Indicators | Curing agent 6801 A | Resin agent 6801 B |
| Appearance | Transparent yellow Liquid | Black Liquid |
| Viscosity (CPS) | 250±100 | 600±200 |
| Mixed viscosity (CPS) | 450±150 |
| Density (g/cm³ .25℃) | 1.28±0.05 | 0.95±0.05 |
| Usage ratio (weight ratio) | A:B=1:1 |
| Pot life 100g (min. 25 ℃) | 25±5 |
| Curing conditions | Room temperature curing or heating curing |
| Gel time (min.25 ℃) | 40-60 |
| Color (after curing) | Black |
| Hardness (ShoreA/D) | 45±10A |
| Curing time（23~25℃） | 3-5H |
| Curing time (Heating) | 80 ℃ for 20 minutes |
| Temperature resistance (℃) | -40℃~100℃ |
| Water absorption (24H) | ≤0.5% |
| Anti-UV Grade（GB/T14522-2008） | / |
| Thermal conductivity (W/m.k) | 0.3 |
| Dielectric Strength (kV/mm) | 24 |
| Surface Resistivity (Ω/sp) | 1.88×1015 |
| Volume resistivity (Ω.cm) | 1.25×1014 |
| Flame retardant (UL94) | V0 |
| Dielectric constant (1K Hz) | 4.41 |
| Tensile strength (MPa) | / |
| Ultimate elongation (%） | / |
| Average coefficient of linear expansion | 156×10-6K-1 |
| Electrification index (CTI) | / |
The online data is for reference only, please contact us to get the latest version, and the official TDS data shall prevail.
